In our last post, we have refactored a sample application to be spot ready. Then we ran its entire stack on spot instances. However, one caveat is if particular spot instances were temporary not available in the market, we would fail back on demand instances in autoscaling group. It’s perfectly okay, but we are going to take cost optimization to the next level. In this post, we will introduce how to improve cost optimization Spot Fleet + autoscaling and also achieve high availability.

Cost Optimization Spot Fleet + Docker

We did lots of work to convert everything into docker, now it’s time to reap the effort. A better cost optimization solution is AWS Spot Fleet. Spot Fleet is a request for a collection of spot instances. It also attempts to maintain its target capacity fleet if your Spot instances are interrupted due to a change in Spot prices or available capacity. Instance flexibility is the key to leverage Spot Fleet to maintain a target capacity. As you may remember, we have talked about instance flexibility in the past. It’s really important because you can use “unpopular” instances in the spot market to replace “popular” instance in any time frame to maintain your target capacity.

Instance Fleet Launch Configuration

Let’s use our previous application as example. Instead of request one time spot instance in the autoscaling group, we are going to use Spot Fleet. Luckily, AWS has announced autoscaling group for spot fleet in the 2016 Sep. The cloudformation should look like this:

  SpotFleet:
    Type: AWS::EC2::SpotFleet
    Properties:
      SpotFleetRequestConfigData:
        IamFleetRole: !GetAtt IAMFleetRole.Arn
        SpotPrice: !Ref 'EC2SpotPrice'
        TargetCapacity: !Ref 'DesiredCapacity'
        TerminateInstancesWithExpiration: false
        AllocationStrategy: lowestPrice
        LaunchSpecifications:
          - InstanceType:  c3.large
            ...
          - InstanceType: c3.xlarge
            ...

As you may notice we have specified two launch configuration set in Spot Fleet request example. In a real scenario, we should specify as many launch configuration as we could, that’s the power of instance flexibility. We don’t really care what instance type it is, because most of instance type can join ECS cluster. Though listing many launch configuration can be painful, here is a interesting approach from us – Programmatic Cloudformation Template.

AutoScaling

Next thing is to add autoscaling group to cope with spike traffic and resource consumption. There are two level of autoscaling. One is at container level and the other is at ECS cluster level. Don’t worry we were confused at the beginning. Here is how it works. Let’s assuming SQS queue number is our scale measurement metrics. It would first scale up number of worker container if SQS queue backup. In any case, the ECS CPU has been utilized more than 70% , then it will scale up the number of spot instance in ECS to keep it overall CPU utilization under 70%. When the SQS queue drop down, it would scale down number of worker container. If the ECS CPU utilization has dropped lower than 30%, it will scale down the number of spot instances until minimum capacity.  Following code are for autoscaling.

Container level:

  apiServiceScalingTarget:
    Type: AWS::ApplicationAutoScaling::ScalableTarget
    DependsOn: apiService
    Properties:
      MaxCapacity: 4
      MinCapacity: 1
      ResourceId: ...
      RoleARN: !GetAtt [AutoscalingRole, Arn]
      ScalableDimension: ecs:service:DesiredCount
      ServiceNamespace: ecs
  apiServiceScalingPolicy:
    Type: AWS::ApplicationAutoScaling::ScalingPolicy
    Properties:
      PolicyName: AStepPolicy
      PolicyType: StepScaling
      ScalingTargetId: !Ref 'apiServiceScalingTarget'
      StepScalingPolicyConfiguration:
        AdjustmentType: PercentChangeInCapacity
        Cooldown: 60
        MetricAggregationType: Average
        StepAdjustments:
        - MetricIntervalLowerBound: 0
          ScalingAdjustment: 200
  workerServiceScalingTarget:
    Type: AWS::ApplicationAutoScaling::ScalableTarget
    DependsOn: workerService
    Properties:
      MaxCapacity: 4
      MinCapacity: 1
      ResourceId: ...
      RoleARN: !GetAtt [AutoscalingRole, Arn]
      ScalableDimension: ecs:service:DesiredCount
      ServiceNamespace: ecs
  workerServiceScalingPolicy:
    Type: AWS::ApplicationAutoScaling::ScalingPolicy
    Properties:
      PolicyName: AStepPolicy
      PolicyType: StepScaling
      ScalingTargetId: !Ref 'workerServiceScalingTarget'
      StepScalingPolicyConfiguration:
        AdjustmentType: PercentChangeInCapacity
        Cooldown: 60
        MetricAggregationType: Average
        StepAdjustments:
        - MetricIntervalLowerBound: 0
          ScalingAdjustment: 200
  DemoALB500sAlarmScaleUp:
    Type: AWS::CloudWatch::Alarm
    Properties:
      EvaluationPeriods: '1'
      Statistic: Average
      Threshold: '10'
      AlarmDescription: Alarm if our ALB generates too many HTTP 500s.
      Period: '60'
      AlarmActions: [!Ref 'workerServiceScalingPolicy']
      Namespace: AWS/ApplicationELB
      Dimensions:
      - Name: ECSService
        Value: !Ref 'apiService'
      ComparisonOperator: GreaterThanThreshold
      MetricName: HTTPCode_ELB_5XX_Count

ECS Cluster level:

  FleetCPUAlarmScaleUp:
    Type: AWS::CloudWatch::Alarm
    DependsOn: DemoCluster
    Properties:
      EvaluationPeriods: '1'
      Statistic: Average
      Threshold: '70'
      ComparisonOperator: GreaterThanThreshold
      AlarmDescription: Alarm if target instance CPU is overloaded
      Period: '60'
      AlarmActions: [!Ref 'FleetScalingUpPolicy']
      Namespace: 'AWS/ECS'
      Dimensions:
      - Name: ClusterName
        Value: !Ref 'DemoCluster'
      MetricName: CPUUtilization
  FleetCPUAlarmScaleDown:
    Type: AWS::CloudWatch::Alarm
    DependsOn: DemoCluster
    Properties:
      EvaluationPeriods: '1'
      Statistic: Average
      Threshold: '30'
      ComparisonOperator: LessThanOrEqualToThreshold
      AlarmDescription: Alarm if target instance CPU is underutlized
      Period: '120'
      AlarmActions: [!Ref 'FleetScalingDownPolicy']
      Namespace: 'AWS/ECS'
      Dimensions:
      - Name: ClusterName
        Value: !Ref 'DemoCluster'
      MetricName: CPUUtilization

Please checkout the full cloudformation template here. The last but not least, please don’t go crazy on biding price in the spot market,as it already saves 80% cost comparing to on-demand. We usually bid full price on it, because you only pay market prevailing price versus bidding price. Now we are running everything on the spot instance, we will walk through how wrap up work on spot instance 2 minutes termination window.

Enjoy being a “pirate” on AWS! “Take everything you can get and give nothing back.” At least we are smart pirate 🙂
